Pneumatic Pressure Testing Incident – Valve Overpressure Event
Background
Our inspection team supervised a pneumatic pressure test on a valve with a target pressure of 7 bar. Present at the site were our lead inspector, the manufacturer’s quality control representative, a technician, and a third-party inspector (TPI). All personnel were positioned close to the valve, under the assumption that 7 bar was a relatively low pressure and posed minimal risk.
Incident Overview
Pressure was gradually increased using a partially used gas cylinder. The primary pressure gauge showed a rise to 4 bar, then stopped. Assuming the cylinder was empty, it was replaced with a new one; however, the gauge still read 4 bar. The team concluded that pressure was not building.
Suspecting a gauge issue, the valve was cautiously opened to verify. At that moment, a secondary gauge located on the opposite side suddenly registered a pressure spike exceeding 40 bar. The original gauge had malfunctioned; its needle was stuck at 4 bar, giving a dangerously false reading. The actual pressure had far exceeded safe limits, resulting in permanent damage to the gauge.
Fortunately, no injuries occurred; however, the event highlighted a serious lapse in pressure monitoring protocol that could have led to catastrophic consequences.
Root Cause Analysis
1. Instrument failure:
The primary gauge was defective; its needle was stuck, providing inaccurate readings.
2. Single-point monitoring:
The team relied solely on one gauge without cross-verification.
Key Learnings
1. Redundancy is critical:
Always use at least two calibrated gauges during pressure testing to cross-check readings.
2. Treat all pressure testing as high-risk
Even low-pressure tests can escalate into hazardous situations.
3. Maintain a safe distance:
Personnel should remain at a safe distance and use remote monitoring wherever feasible.
4. Pre-test instrument checks
All gauges and instruments must be verified for calibration and functionality before testing begins.
